ASTM A928 Grade UNS S31803 duplex stainless steel pipe is a high-strength electric-fusion-welded (EFW) duplex stainless steel pipe designed for corrosive and offshore service environments. Commonly known as Duplex 2205, features a balanced ferritic-austenitic microstructure (approximately 40–50% ferrite / 50–60% austenite), delivering high strength and excellent resistance to chloride-induced stress corrosion cracking (SCC), pitting, and crevice corrosion.
Key Features:
1) High strength (about 2× that of 304/316 stainless steel)
2) Outstanding resistance to chloride SCC, pitting resistance equivalent number (PREN) typically > 32
3) Suitable for large-diameter EFW pipe production
4) Maintains impact resistance at both ambient and low temperatures
ASTM A928 Gr. UNS S31803 Chemical Composition & Mechanical Property:
Chemical Composition, max, % |
Chemical Composition, % | UNS S31803 | UNS S32205 | UNS S32750 |
C, max | 0.030 | 0.030 | 0.030 |
Mn, max | 2.00 | 2.00 | 1.20 |
P, max | 0.030 | 0.030 | 0.035 |
S, max | 0.020 | 0.020 | 0.020 |
Si, max | 1.00 | 1.00 | 0.80 |
Ni | 4.5-6.5 | 4.5-6.5 | 6.0-8.0 |
Cr | 21.0-23.0 | 22.0-23.0 | 24.0-26.0 |
Mo | 2.5-3.5 | 3.0-3.5 | 3.0-5.0 |
N | 0.08-0.20 | 0.14-0.20 | 0.24-0.32 |
Cu | / | / | 0.5 |
W | / | / | |
Tensile Requirements | UNS S31803 | UNS S32205 | UNS S32750 |
Yield Strength (min)
MPa (psi) | 450 (65,300) | 450 (65,300) | 550 (79,800) |
Tensile Strength (min)
MPa (psi) | 620 (89,900) | 655 (95,000) | 800 (116,000) |
General information:
Standard: ASTM A928
Grade: UNS S31803
Size: OD: 168.3-1829mm; WT: Schedule 10, 40, STD, XS, to 160; L: SRL / DRL / Cut to length
Ends:
1) Beveled ends
2) Plain ends
Available Finishing: solution annealed & pickled (AP); pickled & passivated (P&P); oiled
Package: Loose packing for large diameter pipes, plastic caps on both ends, waterproof material wrapped, wooden frames for safe transport or special requirements
Shipment: Land transportation by truck or train, sea transportation by container shipment or bulk vessel.
